Skid Steer Side Shift Adapter – Universal Quick Attach
Skid Steer Side Shift Adapter – Universal Quick Attach
Get more versatility out of your skid steer attachments with the Top Dog Attachments Side Shift Adapter. Designed for Skid Steer Universal Quick Attach (SSQA) systems, this adapter allows you to shift your attachment to the side for better positioning and access in tight or hard-to-reach areas.
The standard configuration allows your attachment to side shift up to 16 inches or operate in the normal centered position. Left-shift, right-shift, and left-and-right configurations are available, with alternate shift distances ranging from 11 to 22 inches.
Key Features
-
16" standard side shift for improved attachment positioning
-
Available in left shift, right shift, or left/right shift configurations
-
Alternate shift distances available from 11" to 22"
-
Compatible with Skid Steer Universal Quick Attach (SSQA)
-
Can operate in the standard centered position
-
With a power quick attach, repositioning can typically be completed without leaving the operator's seat
-
Existing hydraulic hoses and wiring may remain connected during repositioning when sufficient length is available
-
Moves the attachment forward only 3 inches
-
Heavy-duty construction for skid steer applications
| Adapter Weight | 176 lbs. |
| Overall Width | 61" |
| Forward Offset | 3" |
| Standard Side Shift | 16" |
| Available Shift Range | 11"–22" |
| Mounting System | Skid Steer Universal Quick Attach (SSQA) |
How the Side Shift Adapter Works
To reposition the attachment, release it and set it on level ground. Reposition the skid steer and reconnect to the alternate mounting position on the Side Shift Adapter.
When equipped with a power quick attach, this process can typically be completed without leaving the operator's seat. Always verify that hydraulic hoses and electrical wiring have sufficient length before operating in the shifted position.
Work Smarter With Your Skid Steer
Whether you're working along buildings, fence lines, curbs, ditches, or other areas where precise attachment positioning matters, the Top Dog Side Shift Adapter gives your skid steer greater flexibility without requiring a dedicated side-shifting attachment.
Frequently Asked Questions
How far can the Side Shift Adapter move an attachment?
The standard Side Shift Adapter allows you to shift your skid steer attachment 16 inches to the side while still allowing it to operate in the normal centered position.
What quick attach system does it fit?
The Side Shift Adapter is designed for the Skid Steer Universal Quick Attach (SSQA) system.
Do I have to leave the skid steer to side shift the attachment?
If your skid steer is equipped with a power quick attach, you can typically reposition the attachment without leaving the operator's seat. Always follow proper operating procedures when disconnecting and reconnecting an attachment.
Do I need to disconnect my hydraulic hoses or wiring?
Not necessarily. Hydraulic hoses and electrical wiring are typically long enough to remain connected while repositioning, but hose and wiring length must be confirmed for each attachment and installation before use.
Does the adapter move my attachment farther forward?
Yes. The Side Shift Adapter moves the attachment forward approximately 3 inches from its normal mounting position.
What attachments can I use with the Side Shift Adapter?
The adapter is designed to work with a variety of SSQA skid steer attachments. Compatibility, hydraulic hose length, wiring length, machine capacity, and operating clearance should be confirmed for your specific attachment before use.
Call 800-445-8244 to learn more or order your Side Shift Adapter today.
